PATEFONAS

Type

Direct Drive Manual Turntable

Turntable Speeds

33-1/3, 45 and 78 rpm

Adjust Range

±8 %, ±16 %

Starting Torque

3.3 kg-cm

Build-up Characteristics

0.7 s. from Standstill to 33-1/3 rpm

Wow And Flutter

0.025 % W.R.M.S. (JIS C5521)

Rumble

78 dB (IEC 98A weighted)

Turntable Platter

Brass and aluminium die-cast combined
Diameter: 332mm
Weight: Approx. 3.6 kg (including a rubber mat)

Tonearmas

Type

Universal Static Balance

Effective Length

230 mm

Overhang

15 mm

Tracking Error Angle

Within 2° 32'(at the outer groove of 30 cm (12"") record)
Within 0° 32'(at the inner groove of 30 cm (12"") record)

Offset Angle

22°

Arm-height Adjustment Range

0 - 6 mm

Stylus Pressure Adjustment Range

0 - 4 g (direct reading)

Head Shell Weight

Approx. 7.6 g

Applicable Cartridge Weight Range

(Without the auxiliary weight)
5.6 to 12.0 g
14.3 to 20.7 g (including the head shell)
(With small auxiliary weight)
10.0 to 16.4 g
18.7 to 25.1 g (including the head shell)
(With large auxiliary weight)
14.3 to 19.8 g
23.0 to 28.5 g (including headshell)

Cartridge Mounting Dimension

JIS 12.7 mm Interval

Head Shell Terminal Lug

1.2 mm φ 4-pin Terminal Lug

Terminals

Audio Output

PHONO (Pin Jack), EARTH TERMINAL

General

Power Supply

AC 110 - 240 V, 50 / 60 Hz

Power Consumption

14 W Approx. 0.2 W (standby)

Dimensions (W x H x D)

453 x 173 x 372 mm

Weight

Approx. 18 kg

Accessories

Turntable, Turntable Mat, Dust Cover, EP Record Adaptor, Balace Weight, Auxiliary Weight Small, Auxiliary Weight Big, Head Shell, Overhang Gauge, Screw Set for Cartridge, PHONO Cable, PHONO Earth Lead, AC Mains Lead, Screw Set for Turntable, Owner's Manual
