Produkto aprašymas
Onkyo TX-NR820 namų kino stiprintuvas resyveris Bluetooth, nemokamas siuntimas
- THX® Certified Select™ Reference Sound
- Dynamic Audio Amplification with 180 W/Ch, 5 Hz–100 kHz Frequency Response, and VLSC™ On All Channels
- Supports 5.2.2-Channel Dolby Atmos® and DTS:X™ Playback
- 7 HDMI® Inputs (1 Front*1) / Main Out/Zone 2 Out Supporting Dolby Vision™, HDR10, HLG, and 4K/60p Pass-through and HDCP 2.2
- Ready for Chromecast built-in*2 and DTS Play-Fi®*2
- 5 GHz/2.4 GHz Wi-Fi®, AirPlay, Spotify®, TIDAL, Deezer, Pandora®*3, TuneIn*4
- FireConnect™*5 Wireless Multi-room Audio, Powered Zone 2, Zone 2/3 Pre-/Line Outs, and 7.2-Channel Pre-Outs
The RZ Series
Our premium RZ Our premium RZ Series A/V receivers deliver a significant boost to the dynamism, detail, and accuracy of music and movie soundtracks for a listening experience that packs deep emotional impact. The TX-RZ820 features quality components, such as large custom capacitors, to provide high instantaneous current for fast transients and wideband frequency response down to 5 Hz. Discrete non-phase-shift amp circuits clearly focus the audio image and cut distortion even at floor-shaking volumes.
THX® Certified Select™ Reference Sound
THX Certified Select guarantees the same high-volume sound you experience at a commercial theater in your home. To gain certification, amplifiers must pass the industry's most severe bench-tests covering every aspect of audio performance. THX Certified Select components are ideally suited to rooms where the screen-to-seat viewing distance is approximately 3 meters (10 ft.), and the room volume is approximately 57 cubic meters (2,000 cubic feet).
Unleash Dolby Atmos® or DTS:X™ Home Theater
Object-based soundtracks allow independently mixed sound to play through any speaker in your system, moving above and around you with breathtaking realism. The TX-RZ820 reproduces 5.2.2-channel Dolby Atmos or DTS:X formats, with AccuReflex correcting the phase of direct and indirect sounds for cohesive audio imaging with Dolby Atmos-enabled speakers.
Upmixing Solutions for Legacy Soundtracks
DTS Neural:X™ identifies spatial effects in multichannel soundtracks and upmixes for 3D playback through object-audio-ready speaker systems. Dolby Surround also upmixes legacy sound formats so you can experience multidimensional playback of legacy sound formats in a Dolby Atmos environment.
Music Made Easy with Chromecast built-in*
Stream any music from your smartphone, laptop, or PC to the TX-RZ820 with ease. Control playback with Chromecastenabled apps you know and love from your iPhone, iPad, Android phone or tablet, Mac or Windows® laptop, or Chromebook™.
*Available via firmware update.
Stream Anything with DTS Play-Fi®*
DTS Play-Fi® is a wireless protocol that works with any audio app on mobiles and PC. Flick whatever's playing to the receiver, even different sources to different components at the same time.
Requires a future firmware update
FireConnect™ Wireless Multi-room Audio
FireConnect™ mirrors network audio and external analog sources connected to a master component, from streaming services to vinyl records on FireConnect™-compatible speakers in other rooms. Music selection, speaker grouping, and playback management across the home are built into Onkyo Controller app for iOS and Android™.
Note: Sharing audio from external inputs depends on the model and is enabled with a future firmware update. Sampling rates of 44.1 kHz and 48 kHz are supported. FireConnect™ is a technology based on Blackfire provided by Blackfire Research Corp., USA.
Wide Connectivity for Custom Setups
With 7.2-channel pre-outs, 12 V trigger, IR input, and optional rack-mount kit, the TX-RZ820 easily integrates other components (such as outboard amps) to create a full wired multi-room setup thanks to Powered Zone 2A/2B and Zone 2/3 Pre-/Line Outputs governed by a Whole Home Audio Mode and supported within Onkyo Controller. RS-232 and IP Control via LAN are ready for home automation systems.
Wi-Fi®, AirPlay, Spotify®, and Bluetooth®
Selectable 5 GHz/2.4 GHz Wi-Fi® assures stable connectivity so you can enjoy smooth streaming over AirPlay, the Spotify app, and the local network. Bluetooth wireless technology also provides quick streaming from your choice of music application.
Internet Radio and Streaming Services
TIDAL, Deezer, Pandora®, and TuneIn are on board to make selecting from a massive range of music and radio programs using Onkyo Controller very simple.
Supports HDR10, HLG, Dolby Vision™, BT.2020, 4K/60 Hz, and HDCP 2.2
Six rear HDMI® inputs, Main Out, and Zone 2 Out support pass-through of HDR10, HLG (Hybrid Log-Gamma), and Dolby Vision; the BT.2020 4K video standard; 4K/60 Hz video playback; and HDCP 2.2 for premium video content. Front HDMI terminal is ideal for video camera connection, while the Zone 2 output distributes home theater video to a display in a second room.
MULTI-ZONE AUDIO AND VIDEO
Pre-outs for Zone 3 as well as Powered Zone 2A/B capability opens up distributed audio options throughout the home backed by dedicated Zone 2 and Zone 3 DACs.
NOISELESS AUDIO PROCESSING
Vector Linear Shaping Circuitry is a mouthful, so we call it VLSC™. This circuitry virtually removes digital pulse noise for a smooth analog signal. RZ820 focuses VLSC on the front left and right channels.
Data is converted between sampling points and these points are joined with analog vectors in real time to produce a smooth output wave form. The result is a virtually noiseless, smooth, analog signal based on the digital source. It brings out even the most subtle of nuances in audio sources.
LIMITLESS PERFORMANCE. INSTALLATION FRIENDLY.
The Onkyo RZ Series was designed for home theater integration and performance above and beyond your expectations. From multi-zone audio and video options to dedicated RZ Series phone support and a three-year product warranty, the Onkyo RZ Series delivers superior audio performance in the configurations you want with the support you should expect from the leader in home audio.
PRIORITY SUPPORT & THREE YEAR WARRANTY
Onkyo RZ Series specialists are specifically trained to troubleshoot any issues you encounter on an install via a dedicated support line. Onkyo RZ Series products are backed by a three-year warranty should a product ever require service or replacement.
| Galingumas | |
| Visi kanalai | 250 W/Ch (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven, FTC) 130 W/Ch (8 Ohms, 20 Hz–20 kHz, 0.08% THD, 2 Channels Driven, FTC) |
| Dynamic Power | 300 W (3 Ohms, Front) 250 W (4 Ohms, Front) 150 W (8 Ohms, Front) |
| THD+N (Total Harmonic Distortion + Noise) | 0.08% (20 Hz–20 kHz, Half Power) |
| Damping Factor | - |
| Įėjimo jautrumas Ir varža | 200 mV/47 k-ohms (Line) 3.5 mV/47 k-ohms (Phono MM) |
| Rated RCA Output Level and Impedance | 1.0 V/320 Ohms (Pre Out) 1.0 V/470 Ohms (Subwoofer Pre Out) 200 mV/2.3 k-ohms (Zone 2/3 Line Out) 2.0 V/2.3 k-ohms (Zone 2/3 Pre Out) |
| Maximum RCA Output Level and Impedance | - |
| Phono Overload | 70 mV (MM, 1 kHz, 0.5%) |
| Frequency Response | 5 Hz–100 kHz/+1 dB, -3 dB (Direct Mode) |
| Tone Control | ±10 dB, 90 Hz (Bass) ±10 dB, 7.5 kHz (Treble) |
| Signalo/triukšmo santykis | 106 dB (Line, IHF-A) 80 dB (Phono, IHF-A) |
| Speaker Impedance | 4 ohms–16 ohms |
| Video Section | |
| Input Sensitivity/Output Level and Impedance | - |
| Video | 1.0 Vp–p/75 Ohms (Component Y) 0.7 Vp–p/75 Ohms (Component PB/CB, PR/CR) 1.0 Vp–p/75 Ohms (Composite) |
| Component Video Frequency Response | 5 Hz–100 MHz/+0 dB, -3 dB |
| Tuner Section | |
| Tuning Frequency Range | |
| FM | 87.5 MHz–1070.9 MHz |
| AM | 530 kHz–1,710 kHz |
| FM/AM Preset Memory | 40 stations |
| General | |
| Maitinimas | AC 120 V~, 60 Hz |
| Power Consumption | 650 W |
| No-Sound Power Consumption | 70 W |
| Standby Power Consumption | 0.15 W |
| Matmenys | 17 1/8" x 7 15/16" x 15 9/16" (435 x 202 x 395 mm) |
| Svoris | 30.9 lbs (14.0 kg) |
| Carton | |
| Dimensions (W x H x D) | 21 5/8" x 11 15/16" x 18 11/16" (550 x 303 x 490 mm) |
| Weight | 37.5 lbs (17.0 kg) |
