Savybės:

• Three-way, fully horn-loaded loudspeaker
• One watt can generate a concert sound experience
• Clarity, accuracy, and remarkable tonal definition
• A best-in-class, highly durable speaker enclosure assembled with pride in Hope, AR as part of the Klipsch Heritage Series
• Available in Natural Cherry, Satin Black Ash and American Walnut book-matched veneers to complement any space

Techniniai duomenys

FREQUENCY RESPONSE  (+/- 4 dB)
51Hz – 20kHz

SENSITIVITY
105dB @ 2.83V / 1m

POWER HANDLING
100W / 400W

MAXIMUM SPL
121dB

NOMINAL IMPEDANCE
8 ohms compatible

CROSSOVER FREQUENCY
HF: 4500Hz  MF: 450Hz

TWEETER
K-771 1" (2.54cm) Light-Weight Polyimide Diaphragm Compression Driver Mated to a 90° x 40° Tractrix Horn

HIGH FREQUENCY HORN
Tractrix

MIDRANGE
K-55-X 2” (5.08cm) Phenolic diaphragm compression driver

MID-FREQUENCY HORN
Exponential

WOOFER
K-33-E 15” (38.1cm) Fiber-composite cone with a folded horn

ENCLOSURE MATERIAL
Birch plywood and MDF

ENCLOSURE TYPE
Fully horn-loaded

HEIGHT INCHES (MM)
40” (101.6 cm)

WIDTH INCHES (MM)
24 1/4” (61.59 cm)

DEPTH INCHES (MM)
25 5/16” (64.29 cm)

PRODUCT WEIGHT LBS (KG)
201 lbs (91 kg)

FINISHES
Natural Cherry, Satin Black Ash and American Walnut

GRILLE CLOTH
Silver Metallic

BUILT FROM
2018
