| Name / Model No. | M5 | Operating System | Linux |
| CPU model | Ingenic X1000E | No. of cores | Single |
| CPU operating frequency | 1GHz | DAC | AK4377 |
| Special features | 1. All bluetooth receive codec+Lossless bluetooth transmit 2. Recording+Bluetooth phone call 3. Gesture operation 4. Step counter 5. Custom screen orientation 6. USB Audio 7. USB DAC 8. Multi-style lock screen clock display 9. Use with watchband 10. Supports PO/LO/Spidf output |
User interface | Customized |
| Chips used | Soc:Ingenic X1000E ; DAC:AK4377 ; Bluetooth chip:CSR8675 | ||
| Connectivity | |||
| Bluetooth | 4.2 | Bluetooth transmit | SBC/aptX/LDAC |
| USB | TYPE C Two-way USB2.0 | Bluetooth receive | SBC/AAC/aptX/aptX HD/LDAC |
| Display screen | |||
| Display size | 1.54 | Number of colours | 262K |
| Display type | IPS TFT | Viewable angle | Full-view |
| Resolution | 240×240 | Pixel density(PPI) | 220.4 |
| Touchscreen | Single-touch | ||
| Storage | |||
| RAM | 64MB | Storage card | Micro SD |
| Maximum storage expansion | Theoretically 2TB (only one micro SD card slot) | ||
| Buttons and ports | |||
| Buttons | Physical button+Touch screen | Headphone out (PO) | 3.5 mm headphone jack |
| Line out (LO) | 3.5 mm port(shared PO) | SPDIF output | 3.5 mm port(shared PO) |
| USB | Two-way TYPE C USB2.0(Charging/Data transmisson/USB DAC/USB Audio) | ||
| General | |||
| Color | Black, Red, Blue, Silver, Titanium | Dimensions | 45.3*42*13.7mm |
| Weight | 38g | Volume control | 60 steps +/- button control |
| Recommended headphone impedance | 16~100Ω | Equalizer | 5-band EQ (±6dB), 7 presets+custom preset |
| Balance control | ±5dB | PO | Up to 384kHz-32bit/DSD128 |
| Spdif | Up to 176.4kHz-24bit/DSD64 | USB DAC | Up to 384kHz-32bit/DSD128 |
| USB Audio | Up to 384kHz-32bit/DSD128 | ||
| Power specifications | |||
| Battery | 3.7V Li-polymer battery | Battery capacity | 550mAh |
| Charging indication | Status bar indication, Shutdown charging indication |
Charging time | <2.5h |
| Battery indication | Status Bar Battery indicator | Deep sleep time | 22 days |
| Battery Life & Test Conditions | |||
| 3.5mm headphone output:>10.5h | |||
| Volume | 24 | Load | M3 open earbuds (27 Ω) |
| Screen | OFF | Test File | MP3 44.1kHz/16bit |
| Bluetooth transmit:>12h(SBC) | |||
| Volume | 24 | Load | BTR1 |
| Screen | OFF | Test File | MP3 44.1kHz/16bit |
| Bluetooth receiving:13.5h(SBC) | |||
| Volume | 50 | Load | M3 open earbuds (27 Ω) |
| Screen | OFF | Test File | MP3 44.1kHz/16bit |
| Others | |||
| Firmware Upgrade | Supports via zip file | Clock | Yes |
| Recording | Yes | Step counter | Yes |
| Headphone out specifications 1(3.5mm port) | |||
| Output power 1 | ≥42mW(16Ω / THD+N<1%) | Output impedance | <0.5Ω |
| Output power 2 | ≥24mW(32Ω / THD+N<1%) | THD+N | <0.003%(1kHz/32Ω) |
| Output power 3 | ≥2.7mW(300Ω / THD+N<1%) | Separation | 74dB |
| Frequency response | 5~90KHz(-3dB) | SNR | ≥118dB |
| Noise floor | <2.5μV | ||
| File format support | |||
| Lossless: | DSD:DSD64,128(“.iso”“.dsf”,“.dff”) APE(Fast): 384 kHz/24 bit APE(Normal): 96 kHz/24 bit APE (High): 96kHz/24 bit APE (Extra High): not supported APE (Insane): not supported FLAC: 384kHz/24 bit WAV: 384 kHz/32 bit Aiff:192 kHz/32bit Aif:192 kHz/24 bit WMA Lossless: 96 kHz/24 bit Apple Lossless: 192 kHz/24 bit |
||
| Lossy compression: | MP3,OGG,WMA,AAC… | ||
